Refrigerant Line Arrangement for 1993 Mercedes-Benz 300SL
No.
Part # / Description / Price
Price
17
Piping
Mercedes-Benz
Mercedes-Benz Description: Expansion-valve-to-compressor refrigerant line to partition panel.
20
MSRP $4.30
$3.28
23
Grommet Mercedes-Benz
Mercedes-Benz Description: From expansion valve to compressor. Return line thru fire wall. Feed line to fire wall. For fuel hose through wall, spare wheel recess. For starter cable through partition wall. (starter cable through pedal floor). (to seal vacuum connection at ate booster brake). Hose thru fire wall.
38
Grommet Mercedes-Benz
Mercedes-Benz Description: Fluid-reservoir-to-expansion-valve refrigerant line. For accelerator pedal through front wall. Pedal lever through front panel. Flexible shaft thru fire wall. For flexible drive shaft. At covering. (for suction hose and pressure hose through cowl). Floor water drain,rear right. For pressure hose through front wall.
41
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Heater. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. HEATING. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. MOUNTING PLATE TO DRI ...
MSRP $3.70
$2.79
MSRP $3.70
$2.79
56
MSRP $60.00
$44.28
65
MSRP $99.00
$71.98
68
MSRP $100.00
$73.20
68
Temperature Sensor Mercedes-Benz
Mercedes-Benz Description: At liquid tank,for additional blower. Outdoor temperature sensor.
71
Sealing Ring Mercedes-Benz
Mercedes-Benz Notes: EXHAUST STOCK OF OLD PARTS UNTIL EMPLOYMENT OF R134-A REFRIGERANT
Description: Pressure switch to liquid tank used for additional blower. 9.0 x 1.8 mm. Pressure switch to liquid tank used for compressor. 9.0 x 1.8 mm. At liquid tank. 9.0 x 1.8 mm. Refrigerant reservoir valve. 9.0 X 1.8 MM. Sensor. 9.0 x 1.8 mm.
74
Protective Cap Mercedes-Benz
Mercedes-Benz Description: Pressure switch to liquid tank used for additional blower. Door contact switch. Front door.
77
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Description: M5x10.5. At blower;temperature sensor ventilation. Bracket to fire wall. Heat shield mounting. Control unit. Screening plates. Main floor,front right. Return line to partition panel.
MSRP $0.70
$0.51
MSRP $0.70
$0.51
80
MSRP $109.00
$79.30
86
Nut Mercedes-Benz
Mercedes-Benz Description: Pipe line to shock absorber leg reinforcement. Pipe line to valve. Hinge lever to engine hood.
89
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
92
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
98
Discharge Line Valve Mercedes-Benz
Mercedes-Benz Description: Condenser. To 140 830 05 70. To 129 830 02 70,129 830 04 70. Filling valve. In pressure line.
MSRP $22.50
$17.13
MSRP $22.50
$17.13
98
Valve Element Mercedes-Benz
Mercedes-Benz Description: To 129 830 01 70. To 140 830 20 15. Compressor-to-condenser refrigerant line.
MSRP $10.50
$8.00
MSRP $10.50
$8.00
101
MSRP $9.75
$7.37
107
MSRP $31.00
$23.50
113
Intermediate Layer Mercedes-Benz
Mercedes-Benz Description: Condenser to stiffening and to front cross member. Condenser to front central stiffening and to support,bottom.
MSRP $2.20
$1.65
MSRP $2.20
$1.65
116
Grommet Mercedes-Benz
Mercedes-Benz Description: Hole plug for vacuum pump. 12 mm. Front left. 12 mm.
MSRP $1.70
$1.27
MSRP $1.70
$1.27
119
Intermediate Layer Mercedes-Benz
Mercedes-Benz Description: Additional blower to condenser. Condenser to radiator.
MSRP $19.50
$14.61
MSRP $19.50
$14.61
128
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Engine hood upper catch to engine hood. Flap to hinge m 6x10.
MSRP $2.90
$2.16
MSRP $2.90
$2.16
131
Bolt And Washer Assembly Mercedes-Benz
Mercedes-Benz Description: Additional blower to additional blower. Auxiliary fan to strut. Oil cooler.
137
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: LEFT GRAB HANDLE MOUNTING
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm.
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm.
140
MSRP $3.00
$2.29
146
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Amplifier at c-pillar. Amplifier to bracket. Reinforcem. At bracket, left.
MSRP $3.50
$2.67
MSRP $3.50
$2.67
149
MSRP $0.90
$0.64
185
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Rear lid to hinge lever. Drive to rear pillar. Pipe line to shock absorber leg reinforcement. Strut to front cross member. Bracket to car floor. Cooling pipe to front cross member. Engine hood upper catch to engine hood. Partition panel. Strut to stiffening,front central.
188
MSRP $11.00
$8.38
