Wiring Harness for Semi-Active Air Suspension for 1994 Mercedes-Benz E500
No.
Part # / Description / Price
Price
5
Acceleration Sensor
Mercedes-Benz
Mercedes-Benz Description: Lat. Acceleration sensor in wheelhouse, front axle left and right. Front axle vertical accelerator sensor. Acceleration sensor on spring/shock absorber turret. Acceleration, vertical.
MSRP $142.00
$103.70
MSRP $142.00
$103.70
5
Acceleration Sensor Mercedes-Benz
Mercedes-Benz Description: Lat. Rear axle vertical accelerator sensor. Acceleration sensor on spring/shock absorber turret. Front axle vertical accelerator sensor. Acceleration sensor, left and right front.
MSRP $76.00
$55.97
MSRP $76.00
$55.97
15
MSRP $8.00
$6.03
25
Hexagon Nut With Collar Mercedes-Benz
Mercedes-Benz Description: Oxygen sensor. 5 mm. Bracket mounting. 5 mm. Control module,auxiliary fan. 5 mm.
MSRP $4.00
$3.05
MSRP $4.00
$3.05
30
Turning Angle Sensor Mercedes-Benz
Mercedes-Benz Description: Level sensor in wheelhouse, left front axle. Rear axle level sensor.
MSRP $250.00
$174.28
MSRP $250.00
$174.28
30
Turning Angle Sensor Mercedes-Benz
Mercedes-Benz Description: Headlamp range adjustment front. Level sensor to bracket, rear axle. Turning angle sensor. Rear axle level sensor, headlamp range adjustment. Rear axle level sensor for air suspension. Level sensor to front axle wheelhouse. Level sensor in wheelhouse, left front axle. Level sensor for bi-xenon rear axle.
MSRP $206.00
$143.91
MSRP $206.00
$143.91
50
MSRP $1.50
$1.14
50
Screw Mercedes-Benz
Mercedes-Benz Description: M5X8
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Sensor mounting on front axle right. Sender unit to bracket. Bracket on rear axle m 5. Travel sensor to bracket. Fastening sensor to front axle. Bracket to turning angle sensor m5 x 8. Fastening sensor to rear axle. Turning angle sensor at bracket.
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Sensor mounting on front axle right. Sender unit to bracket. Bracket on rear axle m 5. Travel sensor to bracket. Fastening sensor to front axle. Bracket to turning angle sensor m5 x 8. Fastening sensor to rear axle. Turning angle sensor at bracket.
110
Control Unit Mercedes-Benz
Mercedes-Benz Description: Pneumatic suspension. Air suspension semi-active.
MSRP $970.00
$661.20
MSRP $970.00
$661.20
110
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Pneumatic suspension. Air suspension semi-active.
150
Holder Mercedes-Benz
Mercedes-Benz Description: To exhaust bracket plugged in right. To exhaust bracket plugged in left. To cable holder wheel carrier rear axle clipped left.
180
Wiring Harness Mercedes-Benz
Mercedes-Benz Description: Sensor, level control. Turning angle sensor.
MSRP $60.00
$44.28
MSRP $60.00
$44.28
200
200
200
220
Cover Cap Mercedes-Benz
Mercedes-Benz Description: Speed-sensitive power steering conn. Antenna module. 6-pin. Antenna amplifier to rear window to 001 545 51 40. 6-pin.
240
Plug Mercedes-Benz
Mercedes-Benz Description: Level control system control unit 48-pin. Part 2 to a 001 545 99 40. Air suspension control module n51, 48-pin, to a0015459940. Level control control unit connector n51/3*1. To a 001 545 99 40, 48-pin.
240
Contact Socket Housing Mercedes-Benz
Mercedes-Benz Description: Air suspension control module n51. 48-pin
model 1: mqs / jpt
model 2: 2.8
slots: 48.
model 1: mqs / jpt
model 2: 2.8
slots: 48.
240
Cap Mercedes-Benz
Mercedes-Benz Description: N51/3*1. Part 1 to a 001 545 99 40. Level control system control unit n51/3*3. To a 033 545 75 28. To a 001 545 98 40. To 0015459840. Plug housing to 001 545 98 40. Air suspension control module n51/3.
MSRP $4.50
$3.43
MSRP $4.50
$3.43
250
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Damper adjustment control unit N51/5. 2-pin mqs.
MSRP $5.00
$3.81
MSRP $5.00
$3.81
250
Cover Mercedes-Benz
Mercedes-Benz Description: To 0295454028. 2-pin mqs. Level control control unit connector n51/3*2. 2-pin mqs. Electronic Stability Program control unit TO A 029 545 40 28. 2-PIN MQS. Air suspension control module n51/3. 2-pin mqs.
MSRP $7.25
$5.46
MSRP $7.25
$5.46
260
Contact Socket Housing Mercedes-Benz
Mercedes-Benz Description: Abc control module. 30-pin mqs
model 1: mqs
slots: 30. Control module electronic stability program n30/4,. 30-pin mqs
model 1: mqs
slots: 30. Control unit eps/abc. 30-pin mqs
model 1: mqs
slots: 30. 30-pole. 30-pin mqs
model 1: mqs
slots: 30. Control unit esp. 30-pin mqs
model 1: mqs
slots: 30. Traction system control module 30-polig. 30-pin mqs
model 1: mqs
slots: 30.
model 1: mqs
slots: 30. Control module electronic stability program n30/4,. 30-pin mqs
model 1: mqs
slots: 30. Control unit eps/abc. 30-pin mqs
model 1: mqs
slots: 30. 30-pole. 30-pin mqs
model 1: mqs
slots: 30. Control unit esp. 30-pin mqs
model 1: mqs
slots: 30. Traction system control module 30-polig. 30-pin mqs
model 1: mqs
slots: 30.
MSRP $11.50
$8.64
MSRP $11.50
$8.64
270
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.24
MSRP $9.50
$7.24
270
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$5.33
MSRP $7.00
$5.33
280
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $8.00
$5.97
MSRP $8.00
$5.97
290
Spring Retaining Pin Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
MSRP $3.90
$2.92
MSRP $3.90
$2.92
310
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Air suspension/adapter of rear axle valves.
320
330
Plug Mercedes-Benz
Mercedes-Benz Description: Central antenna separation point (tpm) x1/50. 6-pinmodel 1: mqsslots: 6. Rear axle transfer case plugconnection (x62/8). 6-pinmodel 1: mqsslots: 6. Separation point, micro array x39/69 mic out. 6-pinmodel 1: mqsslots: 6. Separation point, micro array x39/6 ...
MSRP $3.90
$2.92
MSRP $3.90
$2.92
600
Housing Mercedes-Benz
Mercedes-Benz Description: Rear axle transfer case plugconnection x62/32. Rear axle distributor. 4x4-pin. Rear axle transfer case plugconnection x62/8. 4x4-pin. Rear axle,left and right x62/32, x62/33. 4x4-pin. Rear axle separation point x62/8. 4x4-pin.
MSRP $11.50
$8.76
MSRP $11.50
$8.76
