Cable Harness for Comtrol Display System Oms for 2001 Mercedes-Benz C240

Notes: ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. A535915
ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. F433730
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A535916
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. F433731

Notes: NO LONGER AVAILABLE

Notes: TO BE ADAPTED DURING ASSEMBLY

Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS. ================================================================================================= SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION: A 001 546 99 41 GREEN 0.7 - 2.4 MM2 A 002 546 00 41 RED 2.0 - 4.0 MM2 A 002 546 01 41 BLUE 3.5 - 8.0 MM2 A 002 546 11 41 YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2 ===================================================================================================
