Frame Floor Unit Main Cable Harness for 2006 Mercedes-Benz E320
No.
Part # / Description / Price
Price
20
Securing
Mercedes-Benz
Mercedes-Benz Description: Automatic cut-out f30. Auxiliary battery fuse f33.
MSRP $16.50
$12.32
MSRP $16.50
$12.32
30
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Front axle distributor in maj. Ass. Comp. Brake wear indicator x62/7. 2 pin mqs
model 1: mqs
slots: 2. Pressure converter exhaust gas recirculation. 2 pin mqs
model 1: mqs
slots: 2. Brake lining wear indicator plugconnection,rear x88/15. 2 pin mqs
model 1: mqs
slots: 2. Coolant level s41. 2 pin mqs
model 1: mqs
slots: 2.
model 1: mqs
slots: 2. Pressure converter exhaust gas recirculation. 2 pin mqs
model 1: mqs
slots: 2. Brake lining wear indicator plugconnection,rear x88/15. 2 pin mqs
model 1: mqs
slots: 2. Coolant level s41. 2 pin mqs
model 1: mqs
slots: 2.
MSRP $5.75
$4.32
MSRP $5.75
$4.32
35
Pin Housing Mercedes-Benz
Mercedes-Benz Description: Nox sensor separation point x86/1. 4-pin lks. 02 sensor after catalytic converter 4-pin. 4-pin lks. Connector housing, nox sensor connecting point x86/1. 4-pin lks. Differential pressure sensor x25/12. 4-pin lks. Four pin, for oxygen sensor downstream of catalytic converter. 4-pin lks.
MSRP $9.50
$7.24
MSRP $9.50
$7.24
35
Contact Carrier Mercedes-Benz
Mercedes-Benz Description: Nox sensor separation point x86/1. 4-pin lks1.5. 4-pole to 210 540 62 81. 4-pin lks1.5.
MSRP $7.50
$5.72
MSRP $7.50
$5.72
40
Plug Mercedes-Benz
Mercedes-Benz Description: Left front door connector, green x35/1. 2-pin slk2.8model 1: slkmodel 2: 2.8slots: 2. Emergency speaker connector right front x18/36. 2-pin slk2.8model 1: slkmodel 2: 2.8slots: 2. Radio remote control separation point for central locking x35/71. 2-pin slk2 ...
MSRP $5.50
$4.19
MSRP $5.50
$4.19
45
Plug Mercedes-Benz
Mercedes-Benz Description: X86/2. 2-pin mlk1.2. Connector, e-call, teleaid/ir-coc x18/31. 2-pin mlk1.2.
70
Plug Mercedes-Benz
Mercedes-Benz Description: Contact strip driver side yellow x55/3. 12-pin. Intermediate connector, airbag. 12-pin. Cockpit cable harness plug-connection. 12-pin.
100
Contact Support Mercedes-Benz
Mercedes-Benz Description: Connector, rear axle distributor, black x62/8. 4-pin mqs. Rear axle transfer case plugconnection x62/33. 4-pin mqs. Connector, left rear axle electrical distributor, black x62/32*1. 4-pin mqs. Rear axle distributor x62/33. 4-pin mqs. Rear axle separation point x62/8 code a. 4-pin mqs.
MSRP $4.70
$3.56
MSRP $4.70
$3.56
100
Contact Carrier Mercedes-Benz
Mercedes-Benz Description: Connector, left rear axle electrical distributor, violet x62/32*4. 4-pin mqs. Connector, rear axle distributor, violet x62/32,x62/33,cod.d. 4-pin mqs. Rear axle separation point x62/8 code d. 4-pin mqs.
MSRP $4.70
$3.56
MSRP $4.70
$3.56
100
Contact Support Mercedes-Benz
Mercedes-Benz Description: Rear axle transfer case plugconnection x62/8. 4-pin mqs. Distributor rear axle left, neutral x62/32. 4-pin mqs. Rear axle distributor x62/33. 4-pin mqs.
110
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Exhaust gas aftertreatment k27/7. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. Restraint system k40/7. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. K74. 9-pin mdk4, dfk4model 1: mdk / dfkmodel 2: 4slots: 9. Relay, stop lamp suppression 9 ...
MSRP $6.00
$4.57
MSRP $6.00
$4.57
120
Plug Mercedes-Benz
Mercedes-Benz Description: Connector diagnostics x11/4. 16-pin mt3model 1: mtmodel 2: 3slots: 16release tool: w220 589 01 99 54. DIAGNOSIS PLUG. 16-PIN MT3Model 1: MTModel 2: 3Slots: 16Release tool: W220 589 01 99 54. Separation point, cockpit cable harness x35/66. 16-pin mt3model 1 ...
MSRP $20.00
$15.24
MSRP $20.00
$15.24
125
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Data link connector x11/4. 0.5-1.0 mm2 mt3. Separation point, cockpit cable harness x35/66. 0.5-1.0 mm2 mt3. Data link connector x 11/4. 0.5-1.0 mm2 mt3. Connector diagnostics x11/22. 0.5-1.0 mm2 mt3.
MSRP $6.00
$4.57
MSRP $6.00
$4.57
130
Fuse Box Mercedes-Benz
Mercedes-Benz Description: Cool box n10/2. Interior fuse box f1/7. Fuse box interior plug position 25 f34. Fuse box interior plug position 26 f34. Control module sam/srb rear n 10/2. Signal acquisition and actuation module, rear n10/2. Prefuse box at rear light blue f33. Turquoise f34, code c.
MSRP $7.25
$5.46
MSRP $7.25
$5.46
130
Fuse Box Mercedes-Benz
Mercedes-Benz Description: Interior fuse box slot 24 f34. Lower control panel rear f1/7. Sam/srb rear n10/2. Line connection n 10/2. Russet brown f1/6. Plug position: 70 f4. Rear prefuse box, brown f33. Russet brown f34, code b.
MSRP $5.75
$4.32
MSRP $5.75
$4.32
130
Fuse Box Mercedes-Benz
Mercedes-Benz Description: Control module sam/srb front, green n10/1. Instrument panel left f1/7. Sam/srb rear n10/2. Fuse box interior plug position 39 f34. Interior fuse box slot 23 f34. Code black color. Control module sam/srb rear n 10/2. Black f34, code a.
MSRP $3.90
$2.92
MSRP $3.90
$2.92
150
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Can b voltage distributor x30/4. 22-pin.
MSRP $4.50
$3.43
MSRP $4.50
$3.43
200
Plug Mercedes-Benz
Mercedes-Benz Description: Diagnostic socket (lamp unit) e1. 5-pin slk2.8. Delivery unit with fill level sensor a92. 5-pin slk2.8. Fuel pump m3/3. 5-pin slk2.8. Plug connection for fuel pump wiring harness x36/3,code a. 5-pin slk2.8.
MSRP $10.50
$7.75
MSRP $10.50
$7.75
230
Plug Mercedes-Benz
Mercedes-Benz Description: On-board elec. Partition point microphone sound syst. Bus node connector (can) left (coding a) x30/5. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60. Central gateway control module. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60 ...
MSRP $8.00
$5.97
MSRP $8.00
$5.97
240
Distributor Mercedes-Benz
Mercedes-Benz Description: Can bus distributor x30/5. 12x2/1x3 pin. Potential distributor can c x63/4. 12x2/1x3 pin. Can bus c, right x30/19. 12x2/1x3 pin. Can c connector x63/4. 12x2/1x3 pin. Connector can databus x63/4,. 12x2/1x3 pin. Can bus c, left x30/5. 12x2/1x3 pin. Can bus c x30/18. 12x2/1x3 pin. Can bus c, left x63/4. 12x2/1x3 pin. Voltage distributor, can bus 27-pin. 12x2/1x3 pin.
MSRP $37.00
$27.94
MSRP $37.00
$27.94
250
Line Connector Mercedes-Benz
Mercedes-Benz Description: Connector distributor wake-up/ diagnostics 10-pin x30/14. 10-pin slk2.8. Distributor, terminal 58d x30/13. 10-pin slk2.8. Connector distributor wake-up/ diagnostics 10-pin x 30/14. 10-pin slk2.8. Potential distributor kl.31 z204/5. 10-pin slk2.8. Plug distributor wake-up signal 10 pin x30/8,. 10-pin slk2.8. Below left rear seat z204/6. 10-pin slk2.8. Distributor, terminal 15 x30/9,code a. 10-pin slk2.8.
MSRP $7.00
$5.33
MSRP $7.00
$5.33
260
Plug Mercedes-Benz
Mercedes-Benz Description: Automatic rear-end door S62/37. 2 PIN. Diagnosis distronic connector x11/36,code e. 2 pin.
265
Plug Mercedes-Benz
Mercedes-Benz Description: Connector easy-shift manual transm. Automatic transmission plug-connection x22/17. 18 pin.
270
Plug Mercedes-Benz
Mercedes-Benz Description: Connector cockpit/frame floor system x18*2. 6-pin slk2.8model 1: slkmodel 2: 2.8slots: 6release tool: w220 589 01 99 62. Separation point trunk lid 6-pin x8/4. 6-pin slk2.8model 1: slkmodel 2: 2.8slots: 6release tool: w220 589 01 99 62. Connector for engin ...
MSRP $8.50
$6.35
MSRP $8.50
$6.35
275
Coupling Housing, Elec Mercedes-Benz
Mercedes-Benz Description: Wiper motor m6/1. 4-pin slk2.8. Left lighting unit e1. 4-pin slk2.8. Diagnostic socket (lamp unit) e1. 4-pin slk2.8. Plug connection for fuel pump wiring harness x36/3. 4-pin slk2.8. Engine cable harness plug-connection x26. 4-pin slk2.8. Lighting unit e1 e2 (s1). 4-pin slk2.8. Connector X26/2 Engine connecting point. 4-PIN SLK2.8. Plug connection engine/body x26/2. 4-pin slk2.8. Headlamp range adjustment left. 4-pin slk2.8. Lamp unit left and right e1/e2. 4-pin slk2.8.
MSRP $17.50
$13.34
MSRP $17.50
$13.34
280
Plug Mercedes-Benz
Mercedes-Benz Description: Separation point, residual engine heat/differential pressure sensor x25/11. 8-pin slk2.8
model 1: slk
model 2: 2.8
slots: 8. Plug connection for engine,cockpit. 8-pin slk2.8
model 1: slk
model 2: 2.8
slots: 8. Connector, interior/engine black x18/7. 8-pin slk2.8
model 1: slk
model 2: 2.8
slots: 8.
model 1: slk
model 2: 2.8
slots: 8. Plug connection for engine,cockpit. 8-pin slk2.8
model 1: slk
model 2: 2.8
slots: 8. Connector, interior/engine black x18/7. 8-pin slk2.8
model 1: slk
model 2: 2.8
slots: 8.
MSRP $7.50
$5.72
MSRP $7.50
$5.72
285
300
Plug Mercedes-Benz
Mercedes-Benz Description: Plug connection for fuel pump wiring harness x36/3,code a. 4 pin
model 1: jpt
model 2: 2.8
slots: 4. Left lighting unit. 4 pin
model 1: jpt
model 2: 2.8
slots: 4.
model 1: jpt
model 2: 2.8
slots: 4. Left lighting unit. 4 pin
model 1: jpt
model 2: 2.8
slots: 4.
304
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Can connector d x30/39. 3-pin mqs. Connector, drive train can potential distributor x30/21. 3-pin mqs. Powertrain can bus node connector x30/21. 3-pin mqs.
MSRP $6.25
$4.70
MSRP $6.25
$4.70
306
Plug Mercedes-Benz
Mercedes-Benz Description: To electric motor. 8-pin slk2.8. Connector, electronic steering column adjustment x19/2. 8-pin slk2.8. Rpm-sensor signal connector x62. 8-pin slk2.8. Rpm sensor connector, transparent x62. 8-pin slk2.8.
310
Electrical Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 1.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. With single-wire seal. 1.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. With single-wire seal. 1.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 1,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
MSRP $9.75
$7.37
MSRP $9.75
$7.37
325
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH CATCH SPRING,WITH SINGLE-WIRE SEAL. 1.0 MM2 LKS1.5
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: Ag
Model 1: LKS
Model 2: 1.5.
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: Ag
Model 1: LKS
Model 2: 1.5.
MSRP $7.75
$5.84
MSRP $7.75
$5.84
327
Crimp Pin Contact, Rect Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 0.5 MM2 MLK1.2
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MLK
Model 2: 1.2
Release tool: W220 589 01 99 25
Crimp tool: W220 589 01 99 83. With single-wire seal. 0.5 MM2 MLK1.2
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MLK
Model 2: 1.2
Release tool: W220 589 01 99 25
Crimp tool: W220 589 01 99 83.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MLK
Model 2: 1.2
Release tool: W220 589 01 99 25
Crimp tool: W220 589 01 99 83. With single-wire seal. 0.5 MM2 MLK1.2
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MLK
Model 2: 1.2
Release tool: W220 589 01 99 25
Crimp tool: W220 589 01 99 83.
MSRP $5.50
$4.06
MSRP $5.50
$4.06
330
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
MSRP $3.50
$2.67
MSRP $3.50
$2.67
330
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITHOUT SEAL. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85. GOLD. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85. GOLD. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.00
$6.86
MSRP $9.00
$6.86
340
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...
MSRP $3.90
$2.92
MSRP $3.90
$2.92
340
MSRP $3.40
$2.54
350
Contact Spring Mercedes-Benz
Mercedes-Benz Description: 0.35 MM2. 0.22-0.35 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
MSRP $5.00
$3.81
MSRP $5.00
$3.81
360
Plug Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 0.5-0.75 MM2 SLK2.8. Front door connector to frame floor system. 0.5-0.75 mm2 slk2.8. Circuit 15r/58d connector x39/29. 0.5-0.75 mm2 slk2.8. Module box separation point x35/15. 0.5-0.75 mm2 slk2.8. Radio remote control separation point for central locking x35/71. 0.5-0.75 mm2 slk2.8. Silver. 0.5-0.75 mm2 slk2.8. 0,5-1,0mm. 0.5-0.75 mm2 slk2.8. To a 220 545 92 28. 0.5-0.75 mm2 slk2.8.
MSRP $4.00
$3.05
MSRP $4.00
$3.05
365
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: With seal. 1.0 MM2 LKS 1.5
Leitungsquerschnitt Min/Max: 1,0mm2
Model 1: LKS
Model 2: 1.5. Fuel delivery pump control unit n118. 1.0 mm2 lks 1.5
leitungsquerschnitt min/max: 1,0mm2
model 1: lks
model 2: 1.5. Oxygen sensor downstream of catalytic converter g3/5. 1.0 mm2 lks 1.5
leitungsquerschnitt min/max: 1,0mm2
model 1: lks
model 2: 1.5.
Leitungsquerschnitt Min/Max: 1,0mm2
Model 1: LKS
Model 2: 1.5. Fuel delivery pump control unit n118. 1.0 mm2 lks 1.5
leitungsquerschnitt min/max: 1,0mm2
model 1: lks
model 2: 1.5. Oxygen sensor downstream of catalytic converter g3/5. 1.0 mm2 lks 1.5
leitungsquerschnitt min/max: 1,0mm2
model 1: lks
model 2: 1.5.
MSRP $7.50
$4.73
MSRP $7.50
$4.73
365
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Fuel delivery pump control unit n118. 2.5 mm2 lks
leitungsquerschnitt min/max: 2,5mm2
model 1: lks.
leitungsquerschnitt min/max: 2,5mm2
model 1: lks.
MSRP $9.50
$7.11
MSRP $9.50
$7.11
370
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Repair solution contacting 0,75 mm2. MQS. 0.75 MM2 MQS
Leitungsquerschnitt Min/Max: 0,75mm2
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,75mm2
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $7.75
$5.84
MSRP $7.75
$5.84
375
Contact Socket Mercedes-Benz
Mercedes-Benz Description: DOOR LOCK. 0.5-0.75 MM2 SLK2.8Leitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: AgELA: +Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 09. Airbag trigger unit, in front module left and right b48/1. Lighting ...
MSRP $3.70
$2.82
MSRP $3.70
$2.82
375
Contact Socket Mercedes-Benz
Mercedes-Benz Description: Differential pressure sensor B28/8. 1.5-2.5 MM2 SLK2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: +Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 09. SHUTOFF VALVE ACTIVATED-CARBON FILTER Y58. 1 ...
MSRP $3.70
$2.79
MSRP $3.70
$2.79
380
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 1.5-2.5 MM2 JPTLeitungsquerschnitt Min/Max: 1,5-2,5mm2Model 1: JPTModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. Silver-plated, with single-wire seal. 1.5-2.5 MM2 JPTLeitungsquerschnitt Min/Max: 1,5-2,5mm2Model 1: JP ...
MSRP $14.50
$11.01
MSRP $14.50
$11.01
385
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
MSRP $4.90
$3.68
MSRP $4.90
$3.68
385
Spring Retaining Pin Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
MSRP $3.90
$2.92
MSRP $3.90
$2.92
396
Plug Mercedes-Benz
Mercedes-Benz Description: Module box separation point x35/15. 3-pin. Radio remote control separation point for central locking x35/71. 3-pin. Separation point trunk lid 14-pin x8/4. 3-pin. Control unit box/engine sep. Point x35/63. 3-pin.
MSRP $4.40
$3.30
MSRP $4.40
$3.30
400
Housing Mercedes-Benz
Mercedes-Benz Description: Rear axle transfer case plugconnection x62/32. Rear axle distributor. 4x4-pin. Rear axle transfer case plugconnection x62/8. 4x4-pin. Rear axle,left and right x62/32, x62/33. 4x4-pin. Rear axle separation point x62/8. 4x4-pin.
MSRP $11.50
$8.76
MSRP $11.50
$8.76
410
Relay Mercedes-Benz
Mercedes-Benz Description: Changer. Plug position: g/h. Plug position: p. Cooling water pump k60. Tank cap pole reversal 1, slot:. Luggage compartment,right. Slot p. Remote trunk release. K41/1. Filler cap, inner.
500
Electric Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
UP TO IDENT. NUMBER A303555, ORDER OBJECT NUMBER WITHOUT ES1
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
UP TO IDENT. NUMBER A303555, ORDER OBJECT NUMBER WITHOUT ES1
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
Description: Prefuse box feed-in.
510
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Steering wheel heater. Rear seat bench heating.
600
MSRP $97.00
$70.76
625
Fuse Link Mercedes-Benz
Mercedes-Benz Description: Front prefuse box. 40 a. Prefuse box rear. 40 a.
MSRP $8.00
$5.97
MSRP $8.00
$5.97
630
Housing Mercedes-Benz
Mercedes-Benz Description: Prefuse box front, black f32. 1-pin
model 1: lsk
model 2: 8
slots: 1. Rear prefuse box, neutral f33. 1-pin
model 1: lsk
model 2: 8
slots: 1. Rear prefuse box, blue f33. 1-pin
model 1: lsk
model 2: 8
slots: 1.
model 1: lsk
model 2: 8
slots: 1. Rear prefuse box, neutral f33. 1-pin
model 1: lsk
model 2: 8
slots: 1. Rear prefuse box, blue f33. 1-pin
model 1: lsk
model 2: 8
slots: 1.
640
Contact Socket Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, front passenger k40/4. I1. 6.0-10.0 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-10,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56. With single-wire seal. 6.0-10.0 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-10,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
Leitungsquerschnitt Min/Max: 8,0-10,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56. With single-wire seal. 6.0-10.0 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-10,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
MSRP $4.00
$3.05
MSRP $4.00
$3.05
640
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Silver-plated. 4.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgModel 1: LSKModel 2: 8Release tool: W220 589 01 99 56. Central electrics in eng. COMPARTMENT LEFT FRONT N10/1. 4.0 MM2 LSK8 AGLeitungsquerschnitt Min/Max: 4,0mm2Obe ...
MSRP $12.00
$9.02
MSRP $12.00
$9.02
800
Plug Mercedes-Benz
Mercedes-Benz Description: Intermediate connector, airbag x28/12. 12-pin. Connector block, left seat x55/5. 12-pin.
810
Plug Mercedes-Benz
Mercedes-Benz Description: Cockpit/electric steering lock connector x190. 4-pin slk2.8model 1: slkmodel 2: 2.8slots: 4release tool: w220 589 01 99 62. Left rear door connector to frame floor system (x35/3). 4-pin slk2.8model 1: slkmodel 2: 2.8slots: 4release tool: w220 589 01 99 62. ...
MSRP $4.20
$3.18
MSRP $4.20
$3.18
820
Plug Mercedes-Benz
Mercedes-Benz Description: Transmission diagnosis connection x11/32. 2-pin mqs. Radio "mute" plug connection x39/12. 2-pin mqs. Two-way radio speaker separation point x1/45. 2-pin mqs. Connector rear floor frame floor system x8/18. 2-pin mqs. Separation point microphone hands-free system x58/3. 2-pin mqs. M2/2. 2-pin mqs. Separation point aux. Turn sign. Ind. X52/5. 2-pin mqs.
MSRP $2.70
$2.03
MSRP $2.70
$2.03
870
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.24
MSRP $9.50
$7.24
