Steering Gear for 2008 Mercedes-Benz E320
No.
Part # / Description / Price
Price
10
10
10
10
10
10
10
Steering 1
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
IMPORTANT FROM IDENT A 746000 TO A 899999 MIXED INSTALLATION POSSIBLE NOTE PART NO. OF OLD STEERING
IMPORTANT FROM IDENT A 746000 TO A 899999 MIXED INSTALLATION POSSIBLE NOTE PART NO. OF OLD STEERING
10
10
10
10
Steering 1 Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
MSRP $3,800.00
$2,599.20
MSRP $3,800.00
$2,599.20
20
MSRP $60.00
$44.28
20
MSRP $59.00
$43.05
30
MSRP $26.00
$19.69
40
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M14X1.5
Diameter: 14mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 21mm. Tie rod to steering arm. Energy-absorbing unit to plate. Cross strut to shackle. Outside left. Track rod left. Mounting and clamp to energy-absorbing unit.
Diameter: 14mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 21mm. Tie rod to steering arm. Energy-absorbing unit to plate. Cross strut to shackle. Outside left. Track rod left. Mounting and clamp to energy-absorbing unit.
60
Clamping Piece Mercedes-Benz
Mercedes-Benz Description: Inner left and right. 68 MM. Boot to steering. 68 MM. Left and right inside. 68 mm.
MSRP $4.20
$3.18
MSRP $4.20
$3.18
70
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Outer left and right. 15.2-18.5 MM. Exterior. 15.2-18.5 MM. Boot to steering. 15.2-18.5 MM. Left and right outside. 15.2-18.5 mm.
MSRP $3.20
$2.41
MSRP $3.20
$2.41
80
Rubber Bushing Mercedes-Benz
Mercedes-Benz Description: At steering gear. Rack-and-pinion steering.
MSRP $27.50
$20.96
MSRP $27.50
$20.96
90
Repair Kit, Dust Cap Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Steering gear. Parts kit.
90
MSRP $46.00
$34.93
120
MSRP $22.00
$16.51
150
Coupling Socket Mercedes-Benz
Mercedes-Benz Description: To steering. Steering coupling. At steering gear.
MSRP $224.00
$156.78
MSRP $224.00
$156.78
210
MSRP $338.00
$236.34
220
Repair Kit, Steering Gear Mercedes-Benz
Mercedes-Benz Description: For long oil line, with o-rings.
MSRP $80.00
$58.43
MSRP $80.00
$58.43
220
220
Repair Kit, Steering Gear Mercedes-Benz
Mercedes-Benz Description: For short oil line, with o-rings.
MSRP $80.00
$58.43
MSRP $80.00
$58.43
250
Screw Mercedes-Benz
Mercedes-Benz Description: Steering coupling to steering gear. M8x39. Steering joint to steering gear and to steering shaft. Steering coupling to steering shaft and to steering. Lower steering shaft to upper steering shaft. Steering coupling to steering shaft m8 x 40. Screw universal joint. Steering coupling to steering shaft m8 x 39.
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Engine wiring harness connector to solenoid valve (speed-sen. Pow.steer.).
310
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Headlamp cleaning system pump in container. 2 pin jpt. Metering pump. 2 pin jpt. Windshield washer pump;2-pole. 2 pin jpt. As required. 2 pin jpt. Valve to activated charcoal filter y58/1. 2 pin jpt.
MSRP $5.50
$4.19
MSRP $5.50
$4.19
315
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 0.5-1.00 MM2 JPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Model 1: JPTModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. Silver-plated, with single-wire seal. 0.5-1.00 MM2 JPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Model 1: ...
MSRP $8.00
$5.97
MSRP $8.00
$5.97
320
Plug Mercedes-Benz
Mercedes-Benz Description: Speed-sensitive power steering conn. Connector activated charcoal fil. Separation point, engine hood contact switch x42/30. 2-pin mqs
model 1: mqs
slots: 2
release tool: w220 589 01 99 60.
model 1: mqs
slots: 2
release tool: w220 589 01 99 60.
MSRP $6.50
$4.95
MSRP $6.50
$4.95
325
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $8.00
$5.97
MSRP $8.00
$5.97
500
MSRP $55.00
$39.98
510
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Mounting plate to integral carrier. M12X1.5X25
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Steering to front frame-type integral support. Plate to frame-type integral support.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Steering to front frame-type integral support. Plate to frame-type integral support.
MSRP $3.20
$2.41
MSRP $3.20
$2.41
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
