Parktronic System (Pts) for 2009 Mercedes-Benz CLK350
No.
Part # / Description / Price
Price
120
Plug
Mercedes-Benz
Mercedes-Benz Description: Connector, interior and subharness for taillamp x18. 4-pin slk2.8. Connector sun sensor x28/26. 4-pin slk2.8. Hydraulic pump m51/1. 4-pin slk2.8. Warning element/frame floor system connector x35/27. 4-pin slk2.8. Air conditioner case. 4-pin slk2.8. Warning device. 4-pin slk2.8. For blower. 4-PIN SLK2.8. Tail lamp cable harness plugconnection x18. 4-pin slk2.8.
MSRP $6.25
$4.70
MSRP $6.25
$4.70
210
Plug Mercedes-Benz
Mercedes-Benz Description: Module box separation point x35/15. 3-pin. Radio remote control separation point for central locking x35/71. 3-pin. Separation point trunk lid 14-pin x8/4. 3-pin. Control unit box/engine sep. Point x35/63. 3-pin.
MSRP $4.40
$3.30
MSRP $4.40
$3.30
210
Crimp Tml Pin Contact Mercedes-Benz
Mercedes-Benz Description: X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
MSRP $2.80
$2.10
MSRP $2.80
$2.10
215
Receptacle Housing Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Parktronic system. 8-pin rk1.0. Connector, parktronic, front bumper x26/27. 8-pin rk1.0. Repair solution x26/27. 8-pin rk1.0. Connector, front bumper frame floor assembly. 8-pin rk1.0.
220
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Can b voltage distributor x30/4. 22-pin.
MSRP $4.50
$3.43
MSRP $4.50
$3.43
250
270
Plug Mercedes-Benz
Mercedes-Benz Description: Connector sun sensor x28/26. 4-pin slk2.8model 1: mcpmodel 2: 2.8slots: 4release tool: w000 589 13 99 30. HYDRAULIC PUMP M51/1. 4-PIN SLK2.8Model 1: MCPModel 2: 2.8Slots: 4Release tool: W000 589 13 99 30. Connector, interior and subharness for taillamp x18 ...
MSRP $6.00
$4.57
MSRP $6.00
$4.57
280
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.24
MSRP $9.50
$7.24
290
Contact Spring Mercedes-Benz
Mercedes-Benz Description: 0.35 MM2. 0.22-0.35 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 0,22-0,35mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SLK
Model 2: 2.8.
MSRP $5.00
$3.81
MSRP $5.00
$3.81
350
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Parktronic system and keyless go.
360
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: To a 000 545 95 03. To a 001 545 51 40. T0 a 001 545 52 40. To a 001 545 520 40. To a 001 545 28 81. To 001 545 52 40.
MSRP $7.75
$5.84
MSRP $7.75
$5.84
