Refrigerant Line Arrangement for 2013 Mercedes-Benz SL63 AMG
No.
Part # / Description / Price
Price
10
MSRP $68.00
$49.82
20
A/C Line O-Ring
Mercedes-Benz
Mercedes-Benz Description: AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
30
O-Ring Mercedes-Benz
Mercedes-Benz Description: Sprinter van. Type 1. Refrigerant line to mounting plate. 9.5X2.6
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
MSRP $3.20
$2.39
MSRP $3.20
$2.39
60
MSRP $920.00
$627.00
70
Pressure Sensor Mercedes-Benz
Mercedes-Benz Description: Refrigerant line. Reservoir. Sprinter van. Refrigerant condenser. Refrigerant pressure sensor. Roof. Metris. Rear. At condenser,bottom m10.
MSRP $159.00
$115.90
MSRP $159.00
$115.90
140
Line Fastener Mercedes-Benz
Mercedes-Benz Description: Cable fastener M 6. 4.6 X 205 MM. Line to longitudinal member. One passage. Line mounting.
MSRP $3.90
$2.92
MSRP $3.90
$2.92
170
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: SUCTION LINE 13.7X2.5 MM. 13.7X2.5
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
MSRP $14.50
$11.01
MSRP $14.50
$11.01
190
Feed-Through Grommet Mercedes-Benz
Mercedes-Benz Description: Line to suspension strut. Piping mount. Refrigerant line and holder mount.
MSRP $3.00
$2.29
MSRP $3.00
$2.29
200
Snap Fastener Mercedes-Benz
Mercedes-Benz Description: Pressure sensor. Line to longitudinal member. Piping mount. Left and right inner longitudinal member. Mounting to connecting member. Refrigerant line to suspension strut tower. Line mount. To cover. Right rear longitudinal member, upper. Line to connecting member.
MSRP $2.50
$1.91
MSRP $2.50
$1.91
250
Refrigerant Line Mercedes-Benz
Mercedes-Benz Description: From connecting point to compressor.
MSRP $139.00
$101.26
MSRP $139.00
$101.26
260
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Piping to refrigerant compressor. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23,8mmOutside diameter: 28,6mmMaterial thickness: 2,4mm. Refrigerant line. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23, ...
MSRP $3.60
$2.68
MSRP $3.60
$2.68
270
O-Ring Mercedes-Benz
Mercedes-Benz Description: Separation point. 16.7x2.5. Engine Mounted A/C. 16.7 x 2.5mm. All Required. Roof Mounted A/C. 16.7 x 2.5mm. Refrigerant line to refrigerant line. 16.7x2.5. Suction line to compressor. 16.7x2.5. Refrigerant line connecting point. 16.7x2.5.
MSRP $17.00
$12.70
MSRP $17.00
$12.70
300
Screw Cap Mercedes-Benz
Mercedes-Benz Description: Filler connection. High-pressure line. Cover, service connection, high pressure, air conditioning system. Filling connection m10x1. High-pressure side M10X1. To refrigerant line. Valve.
MSRP $6.75
$5.08
MSRP $6.75
$5.08
310
Screw Cap Mercedes-Benz
Mercedes-Benz Description: Filler connection. Filling connection. Low-pressure line. Seal. Suction line. Cover, service connection, low pressure, air conditioning system. Low-pressure side M8X1. To refrigerant line. Valve.
MSRP $12.00
$9.14
MSRP $12.00
$9.14
900
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Accleration sensor at right front b24/4. 3-pin mqs
model 1: mqs
slots: 3. Refrigerant pressure/temperature sensor B12/2. 3-PIN MQS
Model 1: MQS
Slots: 3.
model 1: mqs
slots: 3. Refrigerant pressure/temperature sensor B12/2. 3-PIN MQS
Model 1: MQS
Slots: 3.
MSRP $3.20
$2.39
MSRP $3.20
$2.39
