Control Modules and Relays in Load Compartment for 1994 Mercedes-Benz E320
No.
Part # / Description / Price
Price
5
Control Unit 1
Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Battery control module in trunk.
10
Securing Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Top central partition panel to top left and right partition panels. Fastening battery control module. Guide plate to sliding roof plate. Sliding roof mechanism to sliding roof plate. Mounting, sensor.
12
MSRP $2.40
$1.78
15
MSRP $3.50
$2.67
20
Nut Mercedes-Benz
Mercedes-Benz Description: Spring strut to body. M8
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
50
Holder Mercedes-Benz
Mercedes-Benz Description: Fastening, control modules in trunk lower left. Control unit hitching mechanism.
50
Holder Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Fastening, control modules in trunk lower left.
100
Holder Mercedes-Benz
Mercedes-Benz Description: Fastening, control modules in trunk top left. Control unit fixture.
120
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Rear lid to hinge lever. Drive to rear pillar. Pipe line to shock absorber leg reinforcement. Strut to front cross member. Bracket to car floor. Cooling pipe to front cross member. Engine hood upper catch to engine hood. Partition panel. Strut to stiffening,front central.
140
Elec Center, Base Module 1 Mercedes-Benz
Mercedes-Benz Description: Signal acquisition and actuation module with rear fuse and relay module sam/srb n10/2.
140
Elec Center, Base Module Mercedes-Benz
Mercedes-Benz Description: Signal acquisition and actuation module with rear fuse and relay module sam/srb n10/2.
MSRP $685.00
$472.65
MSRP $685.00
$472.65
150
Relay Mercedes-Benz
Mercedes-Benz Description: Changer. Plug position: g/h. Plug position: p. Cooling water pump k60. Tank cap pole reversal 1, slot:. Luggage compartment,right. Slot p. Remote trunk release. K41/1. Filler cap, inner.
150
Relay Mercedes-Benz
Mercedes-Benz Description: Rear, pos. C,f. Front. HEATED REAR WINDOW PANE RELAYModel 2: Schliesser / closing contactVolt: 12VAmps: 50A. PLUG POSITION: NModel 2: Schliesser / closing contactVolt: 12VAmps: 50A. RELAY SLOT 0, SECONDARY AIR PUMPModel 2: Schliesser / closing contactVolt: ...
150
Relay Mercedes-Benz
Mercedes-Benz Description: Slot K
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. SLOT J
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. PLUG POSITION C
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. SLOT D
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. Slot P
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A.
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. SLOT J
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. PLUG POSITION C
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. SLOT D
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. Slot P
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A.
MSRP $25.00
$19.05
MSRP $25.00
$19.05
160
MSRP $4.20
$3.18
160
Fuse Mercedes-Benz
Mercedes-Benz Description: Charge level recognition f96. Rear fuse box. Blade fuse ATO. Front, 7.5 amp. Trunk, 7.5 amp. Interior, 7.5 amp. Slot 16 lumbar support adjustment. Slot 3, portable ctel uhi.
MSRP $5.00
$3.81
MSRP $5.00
$3.81
205
Screw Mercedes-Benz
Mercedes-Benz Description: M6x18. Rear seat bench backrest to rear panel. Fender to body. Front fender to wheelhouse.
MSRP $2.40
$1.78
MSRP $2.40
$1.78
205
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Description: Upper air regulation system mount. M6x24.
MSRP $3.20
$2.41
MSRP $3.20
$2.41
280
Tapping Screw Mercedes-Benz
Mercedes-Benz Description: Panelling to right front panel pillar. Covering to central partition panel cross member. Covering below instrument panel,left. Bracket to spare wheel well.
MSRP $2.40
$1.78
MSRP $2.40
$1.78
300
MSRP $415.50
$291.33
310
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Remote trunk release.
330
MSRP $9.00
$6.73
350
Bracket Mercedes-Benz
Mercedes-Benz Description: Cable fastening to ret. Cable harness mounting. Electric cable to bracket. Line attachment. Adapter line. To armrest retaining plate. Attachment plate. Line to bracket.
500
Receptacle Mercedes-Benz
Mercedes-Benz Description: Sam/srb control module rear black n10/2. 5-pin slk2.8. Rear sam/srs-fp control module slot 20 n10/2, code a. 5-pin slk2.8.
500
MSRP $4.20
$3.18
500
Housing Mercedes-Benz
Mercedes-Benz Description: "sam" control unit rear n10/2. 5-pin mqs/mcp2.8
model 1: mqs / mcp
model 2: 2.8
slots: 5
release tool: w220 589 01 99 60 / w000 589 13 99 30. N69/1. Left front door control unit. CONNECTOR: 4. 5-PIN MQS/MCP2.8
Model 1: MQS / MCP
Model 2: 2.8
Slots: 5
Release tool: W220 589 01 99 60 / W000 589 13 99 30. Control module sam/srb rear n10/2. 5-pin mqs/mcp2.8
model 1: mqs / mcp
model 2: 2.8
slots: 5
release tool: w220 589 01 99 60 / w000 589 13 99 30.
model 1: mqs / mcp
model 2: 2.8
slots: 5
release tool: w220 589 01 99 60 / w000 589 13 99 30. N69/1. Left front door control unit. CONNECTOR: 4. 5-PIN MQS/MCP2.8
Model 1: MQS / MCP
Model 2: 2.8
Slots: 5
Release tool: W220 589 01 99 60 / W000 589 13 99 30. Control module sam/srb rear n10/2. 5-pin mqs/mcp2.8
model 1: mqs / mcp
model 2: 2.8
slots: 5
release tool: w220 589 01 99 60 / w000 589 13 99 30.
500
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: "sam" control unit rear. 4-pin mcp 2.8. Control module sam/srb front, blue n10/1,. 4-pin mcp 2.8. Sam/srb control module, rear blue n10/2, code c. 4-pin mcp 2.8. Central locking system n10/2 13. 4-pin mcp 2.8. Fuse and relay module, driver n10/1/12. 4-pin mcp 2.8.
500
MSRP $4.20
$3.18
500
Housing Mercedes-Benz
Mercedes-Benz Description: Control module sam/srb rear n10/2. 7-pin mcp2.8. Tail lamp. 7-pin mcp2.8. Glove compartment lamp e13/2. 7-pin mcp2.8.
MSRP $4.90
$3.68
MSRP $4.90
$3.68
500
Plug Mercedes-Benz
Mercedes-Benz Description: Connector: 4hd. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1. Signal acquisition and actuation module with rear fuse and relay module. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1. Sam/srb control module rear black n10/2*4hd. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1.
model 1: mcp
model 2: 2.8
slots: 1. Signal acquisition and actuation module with rear fuse and relay module. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1. Sam/srb control module rear black n10/2*4hd. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1.
500
Plug Mercedes-Benz
Mercedes-Benz Description: On-board elec. Partition point microphone sound syst. Bus node connector (can) left (coding a) x30/5. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60. Central gateway control module. 3-pin mqsmodel 1: mqsslots: 3release tool: w220 589 01 99 60 ...
MSRP $8.00
$5.97
MSRP $8.00
$5.97
500
Plug Mercedes-Benz
Mercedes-Benz Description: Electronic ignition lock (ezs) control unit n73*2. 2-pin mcp2.8. Signal acquisition and actuation module with rear fuse and relay module. 2-pin mcp2.8. Front sam/srb control module, neutral n10/1,. 2-pin mcp2.8. Sam/srb control module rear neutral n10/2, code b. 2-pin mcp2.8. Fuse and relay module, driver n10/1 / 11. 2-pin mcp2.8.
500
Plug Mercedes-Benz
Mercedes-Benz Description: 3rd stop lamp e21. 2-pin mqsmodel 1: mqsslots: 2. Signal acquisition + actuation module with front fuse and relay module n10/1. 2-pin mqsmodel 1: mqsslots: 2. Heated washer nozzle r2/8. 2-pin mqsmodel 1: mqsslots: 2. Control module sam/srb front, green n10 ...
MSRP $5.25
$3.94
MSRP $5.25
$3.94
500
Housing Mercedes-Benz
Mercedes-Benz Description: Dynamic seat pump A77. 5-PIN MQS, MCP2.8Model 1: MQS/MCPModel 2: 2.8Slots: 5Release tool: W220 589 01 99 60 / W000 589 13 99 30. Sam/srb control module rear neutral n10/2,. 5-pin mqs, mcp2.8model 1: mqs/mcpmodel 2: 2.8slots: 5release tool: w220 589 01 99 6 ...
500
Plug Mercedes-Benz
Mercedes-Benz Description: Stop lamp switch, neutral s9/1. 3-pin mcp2.8model 1: mcpmodel 2: 2.8slots: 3release tool: w000 589 13 99 30. Front sam/srb control module, neutral n10/1,. 3-pin mcp2.8model 1: mcpmodel 2: 2.8slots: 3release tool: w000 589 13 99 30. Sam/srb control module r ...
500
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Sam/srb control module rear violet n10/2,code d. 2-pin mcp2.8. Fuse and relay module, rear n10/2. 2-pin mcp2.8.
500
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Bus node (roof) n70. 5-pin mqs/mcp2.8. Front door control unit, black n69/1,n69/2,code a. 5-pin mqs/mcp2.8. Sam/srb control module rear black n10/2,code a. 5-pin mqs/mcp2.8.
500
Housing Mercedes-Benz
Mercedes-Benz Description: Control unit. 5-pin mqs/mcp2.8
model 1: mqs / mcp
model 2: 2.8
slots: 5. Sam/srb control module, rear blue n10/2. 5-pin mqs/mcp2.8
model 1: mqs / mcp
model 2: 2.8
slots: 5.
model 1: mqs / mcp
model 2: 2.8
slots: 5. Sam/srb control module, rear blue n10/2. 5-pin mqs/mcp2.8
model 1: mqs / mcp
model 2: 2.8
slots: 5.
532
Cable Tie Mercedes-Benz
Mercedes-Benz Description: Mounting material. 2,5X100 MM. Adapter line fastening. 2,5x100 mm. Line mounting. 2,5X100 MM. Hose to engine hood hinge. 2,5x100 mm. Fastening, electrical line at connector housing. 2,5x100 mm.
MSRP $1.00
$0.76
MSRP $1.00
$0.76
600
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $8.00
$5.97
MSRP $8.00
$5.97
600
Contact Socket Mercedes-Benz
Mercedes-Benz Description: Silver-plated. 4.0 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30. With single-wire seal. 4.0 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30. With single-wire seal. 4.0 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30.
MSRP $3.00
$2.29
MSRP $3.00
$2.29
600
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.24
MSRP $9.50
$7.24
600
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$5.33
MSRP $7.00
$5.33
600
Contact Socket Mercedes-Benz
Mercedes-Benz Description: STOP LIGHT SWITCH S9/1. 0.5-1.0 MM2 MCP2.8Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. BLOWER REGULATOR N29. 0.5-1.0 MM2 MCP2.8Leitungsquerschn ...
MSRP $5.75
$4.32
MSRP $5.75
$4.32
600
Contact Socket Mercedes-Benz
Mercedes-Benz Description: BUS NODE (ROOF) N70. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. LEFT TAIL LAMP E3. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Mi ...
MSRP $7.00
$5.21
MSRP $7.00
$5.21
750
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
MSRP $4.90
$3.68
MSRP $4.90
$3.68
820
Receptacle Mercedes-Benz
Mercedes-Benz Description: S22/1. Driver seat partially electric seat adjustment switch. Connector: 1. 2-pin slk2.8. Rear-end door control module m111/e. 2-pin slk2.8.
825
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 0.75mm2. 0.75 MM2
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MQS.
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MQS.
MSRP $5.25
$3.94
MSRP $5.25
$3.94
850
Contact Socket Mercedes-Benz
Mercedes-Benz Description: CONNECTOR TERMINAL 30 SBC FEED-IN X151. 4.0 MM2 SLK2.8Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62. CONTROL UNIT FOR REAR SEATS N25/6. 4.0 MM2 SLK2.8Leitungsquerschnitt Min/Max: ...
MSRP $5.00
$3.81
MSRP $5.00
$3.81
