Belt Locking Retractor, Airbag and Sidebag for 1994 Mercedes-Benz E320
No.
Part # / Description / Price
Price
10
Trigger Device
Mercedes-Benz
Mercedes-Benz Notes: FOR REPAIR WORK MAKE SURE THAT ONLY CONTROL UNITS AND SENSORS FROM THE SAME MANUFACTURER ARE INSTALLED.
TWO DIFFERENT MANUFACTURERS MAY NOT BE USED.
Description: Trigger unit to crossmember. Bosch. At cross member below left front seat. Sidebag. Airbag trigger unit.
MSRP $244.00
$170.82
MSRP $244.00
$170.82
10
Control Unit Mercedes-Benz
Mercedes-Benz Notes: FOR REPAIR WORK MAKE SURE THAT ONLY CONTROL UNITS AND SENSORS FROM THE SAME MANUFACTURER ARE INSTALLED.
TWO DIFFERENT MANUFACTURERS MAY NOT BE USED.
Description: At cross member below left front seat temic. Trigger unit to crossmember temic. Sidebag. Airbag trigger unit.
MSRP $112.00
$81.74
MSRP $112.00
$81.74
25
Exchange Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: FOR REPAIR WORK MAKE SURE THAT ONLY CONTROL UNITS AND SENSORS FROM THE SAME MANUFACTURER ARE INSTALLED.
TWO DIFFERENT MANUFACTURERS MAY NOT BE USED.
MIXED MODEL ASSEMBLY POSSIBLE, COMPARE WITH REMOVED PART
MIXED MODEL ASSEMBLY POSSIBLE, COMPARE WITH REMOVED PART
Description: Airbag control module to tunnel roof reinforcement bosch.
25
Exchange Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: FOR REPAIR WORK MAKE SURE THAT ONLY CONTROL UNITS AND SENSORS FROM THE SAME MANUFACTURER ARE INSTALLED.
TWO DIFFERENT MANUFACTURERS MAY NOT BE USED.
MIXED MODEL ASSEMBLY POSSIBLE, COMPARE WITH REMOVED PART
MIXED MODEL ASSEMBLY POSSIBLE, COMPARE WITH REMOVED PART
Description: Temic.
40
Accelerator Sensor For Airbag Mercedes-Benz
Mercedes-Benz Notes: FOR REPAIR WORK MAKE SURE THAT ONLY CONTROL UNITS AND SENSORS FROM THE SAME MANUFACTURER ARE INSTALLED.
TWO DIFFERENT MANUFACTURERS MAY NOT BE USED.
Description: Bosch. Driver/front passenger upfront sensor. In front module.
MSRP $180.00
$126.36
MSRP $180.00
$126.36
40
Control Unit Mercedes-Benz
Mercedes-Benz Notes: FOR REPAIR WORK MAKE SURE THAT ONLY CONTROL UNITS AND SENSORS FROM THE SAME MANUFACTURER ARE INSTALLED.
TWO DIFFERENT MANUFACTURERS MAY NOT BE USED.
Description: To front module, left temic. Driver/front passenger upfront sensor temic. In front module.
50
Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Crash active head restraint. On tunnel.
MSRP $177.00
$124.02
MSRP $177.00
$124.02
55
Ft Seat Air Bag Nut Mercedes-Benz
Mercedes-Benz Description: Air bags. 144 wheelbase. 170 wheelbase. Driver side. Passenger side. Reverse warning.
MSRP $2.80
$2.10
MSRP $2.80
$2.10
810
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.50
$5.66
MSRP $7.50
$5.66
820
Plug Mercedes-Benz
Mercedes-Benz Description: Pressure sensor, front door b48/7,b48/8. 3 pin. Tilting cone sensor. 3 pin. Control unit to side part b48/7, b48/8. 3 pin. Sensor side airbag left a53/1. 3 pin. Airbag pressure sensor b48/7,b48/8,b48/9,b48/10. 3 pin. Sensor sidebag a53, a54. 3 pin. Sensor side airbag right a54. 3 pin.
MSRP $3.00
$2.29
MSRP $3.00
$2.29
830
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITHOUT SEAL. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85. GOLD. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85. GOLD. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.00
$6.86
MSRP $9.00
$6.86
840
Plug Mercedes-Benz
Mercedes-Benz Description: Malfunction indicator lamp aut. Child seat recognition e16. 3-pin mqs. Belt reeling device code: d. 3-pin mqs. Crash active head restraint n139. 3-pin mqs. Crash signal. 3-pin mqs. Plug connector digital crash input. 3-pin mqs. Center console connector x29/6. 3-pin mqs. Door separation point,a-pillar, left x35/1. 3-pin mqs.
MSRP $3.70
$2.79
MSRP $3.70
$2.79
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
